Saint-Gobain’s 3D Tank Liners are high-performance, single-use liners designed for standard 20L to 500L Nalgene tanks. Made from durable Linear Low-Density Polyethylene (LLDPE), these liners feature a robust 5mm sidewall and 7mm bottom construction to ensure strength and stability. Sterilized by gamma irradiation and manufactured in an ISO Class 7 cleanroom, the liners are animal component-free and meet rigorous industry standards including cGMP, QSR, and ISO 9001:2015. Each liner is backed by a Certificate of Conformance and an optional Validation Guide, making them ideal for critical bioprocessing applications.
$81.62
SKU: LR0050L

Relevant Industries

  • Bioprocessing
  • Biotechnology
  • Pharmaceutical Manufacturing
  • Life Sciences

Applications

  • Buffer and Media Storage
  • Chromatography Feed
  • Bioreactor Feed and Harvest
  • Fraction Collection
  • Intermediate Product Hold
  • Final Product Hold
  • Material: Linear Low-Density Polyethylene (LLDPE)
  • Thickness: 5 mm (Sidewall), 7 mm (Bottom)
  • Temperature Range: -80°C to 60°C (-112°F to 140°F)
  • Sterilization: Gamma Irradiated (25–40kGy)
  • Oxygen Transmission Rate: <0.005 cc/m²/24 hr
  • CO₂ Transmission Rate: <1.0 cc/m²/24 hr
  • Water Vapor Transmission Rate: 2.66–2.68 g/m²/24 hr
  • Tensile Strength (MD): 5300 psi
  • Tear Resistance: >800 grams
  • Seam Strength: >25 lbs/in
  • Dart Impact: >1600 grams
  • Manufactured in ISO Class 7 cleanroom
  • Complies with cGMP, QSR, and ISO 9001:2015
  • Biocompatibility Standards:

1. ISO 10993-3 (Genotoxicity) – Meets Criteria

2. ISO 10993-5 (Cytotoxicity) – Meets Criteria

3. USP <88> Class VI Biological Reactivity – Meets Criteria

  • Bacterial Endotoxin: <0.03 EU/mL (USP <85>)
  • Bioburden: <3 CFU/sample (ISO 11737-1)
  • Subvisible Particulate: Meets USP <788>
  • Available with Certificate of Conformance and Validation Guide
  • Optional SAL 10⁻⁶ validated gamma irradiation per ANSI/AAMI/ISO 11137

Need technical support or help with a quote? Contact Us.

Part Number Description Unit/Case (MOQ)
LR0020L 20L, 3D Tank Liner, Fluid contact surface LDPE, Base OD 19.5" (49.5 cm) x HT 21" (53.3 cm), Film Thickness: 5mm (Side Wall) and 7mm (Bottom), Gamma Irradiated 20
LR0050L 50L, 3D Tank Liner, Fluid contact surface LDPE, Base OD 25" (63.5 cm) x HT 34" (86.4 cm), Film Thickness: 5mm (Side Wall) and 7mm (Bottom), Gamma Irradiated 20
LR0100L 100L, 3D Tank Liner, Fluid contact surface LDPE, Base OD 32.5" (82.6 cm) x HT 36" (91.4 cm), Film Thickness: 5mm (Side Wall) and 7mm (Bottom), Gamma Irradiated 20
LR0200L 200L, 3D Tank Liner, Fluid contact surface LDPE, Base OD 38.5" (97.8 cm) x HT 42" (106.7 cm), Film Thickness: 5mm (Side Wall) and 7mm (Bottom), Gamma Irradiated 10
LR0300L 300L, 3D Tank Liner, Fluid contact surface LDPE, Base OD 41" (104.1 cm) x HT 51" (129.5 cm), Film Thickness: 5mm (Side Wall) and 7mm (Bottom), Gamma Irradiated 10
LR0400L 400L, 3D Tank Liner, Fluid contact surface LDPE, Base OD 48" (121.92 cm) x HT 51" (129.5 cm), Film Thickness: 5mm (Side Wall) and 7mm (Bottom), Gamma Irradiated 10
LR0500L 500L, 3D Tank Liner, Fluid contact surface LDPE, Base OD 54" (137.2 cm) x HT 68" (172.7 cm), Film Thickness: 5mm (Side Wall) and 7mm (Bottom), Gamma Irradiated 10
